Adjustable cutterhead with reversible knives for grooves STARK TH09TM

The STARK TH09TM cutter has a diameter of 160 mm, an adjustable height and a borehole diameter of 30 or 35 mm. The cutter head is used for manual and machine feeding of workpieces.

The adjustable groove cutter is made of steel and it has interchangeable HW blades that rotate and do not need to be sharpened. It is used for making grooves in hard and soft solid wood and wood composites up to 30 mm deep.

The cutting height is adjusted with spacer strips with thickness of 0.1 mm.

There are three models of routing heads with different working heights from 8 to 30 mm.

The cutter is suitable for use on conventional router machines and several spindle machines.

The TH09TM01 set includes:

⎻    cutter head,

⎻    four blades 7.65 × 12 × 1.5 mm (600001),

⎻    four blades 14 × 14 × 2 mm (600201),

⎻    spacers.

Technical data:

⎻    cutter diameter: 160 mm;

⎻    working height: 8–15 mm;

⎻    maximum cutting depth: 30 mm;

⎻    borehole diameter: 30 or 35 mm.

The TH09TM11 set includes:

⎻    cutter head,

⎻    four blades 12 × 12 × 1.5 mm (600002),

⎻    four blades 14 × 14 × 2 mm (600201),

⎻    spacers.

Technical data:

⎻    cutter diameter: 160 mm;

⎻    working height: 12.5–24 mm;

⎻    maximum cutting depth: 30 mm;

⎻    borehole diameter: 30 or 35 mm.

The TH09TM03 set includes:

⎻    cutter head,

⎻    four blades 15 × 12 × 1.5 mm (600003),

⎻    four blades 14 × 14 × 2 mm (600201),

⎻    spacers.

Technical data:

⎻    cutter diameter: 160 mm;

⎻    working height: 16–30 mm;

⎻    maximum cutting depth: 30 mm;

⎻    borehole diameter: 30 or 35 mm.
